Production of Solar Modules and Cells

In 2017 Hevel Group began producing of heterojunction solar modules and cells with an efficiency rating over 22%.
Annual output currently stands at 160 MW and this production capacity is set to grow as the Group pursues its development's strategy.

Hotline:

8 800 250 00 56

E-mail: overseas@hevelsolar.com

Buy solar modules and cells

To buy our solar modules, click on the link below.

315 W -
capacity of a Hevel's heterojunction module
  • Heterojunction
    solar module
  • Heterojunction
    solar cell
  • Flexible
    solar elements
  • Sandwich
    panels

Hevel has developed a new solar module production technology based on heterojunction (HJT). Combining the advantages of both thin-film and crystalline technology these new-generation modules have an efficiency rating of at least 22%.

400
kW*h/year
Average power generated by a single module under sun radiation at 1300W/m2
25 years
Guaranteed capacity 80% Pmpp
-60°C +85°C
Operating temperature range

Module specification

Length 1671 mm
Width 1002 mm
Weight 19 kg
Open-circuit voltage 43.5 V
Voltage at rated power 39.2 V
Nominal peak power 300 W,
310 W,
315 W

Hevel's heterojunction solar cell has an efficiency rating totally 23%. Cells could be exported and delivered for the localized assembly.

Cell specification

Length 156,75±0,25 mm
Width
156,75±0,25 mm
Thickness
0,18±0,02 mm
Diagonal 210±0,5 mm
Цeight 10,2±0,2 g
Efficiency, % 22,6 – 22,8
Capacity, W 5,51 - 5,56
Semi flexible high performance heterojunction solar panel can be widely used on yachts, boats or trucks, RV roof as well as architectural elements for different types of buildings.
Light and thin semi-flexible solar modules are highly efficient and resistant to various weather conditions.

For preliminary order, please, send a request to sales@hevelsolar.com

Cell specification

Length 156,75±0,25 mm
Width
156,75±0,25 mm
Thickness
0,18±0,02 mm
Diagonal 210±0,5 mm
Цeight 10,2±0,2 g
Efficiency, % 22,6 – 22,8
Capacity, W 5,51 - 5,56

This high efficient photovoltaic sandwich panel for roofing is jointly developed by Hevel Group and Belarusian company ISOBUD.

This is ready-made and easy to install solution for power-efficient construction. Sandwich panels are widely used in construction of residential frame-panel buildings, logistics centers, sports facilities, parking areas and other infrastructure and also in agrarian sector.

For preliminary order, please, send a request to info@isobud.by.

Module specification

Length 1671 mm
Width 1002 mm
Weight 28 kg
Open-circuit voltage 43.5 V
Voltage at rated power 39.2 V
Nominal peak power 270 W,
290 W,
310 W

Manufacturing Process

Hevel's Plant solar module manufacturing plants is located at Novocheboksarsk, in the Chuvash Republic, Russian Federation.
